Before an in-line inspection (ILI) tool is deployed, engineers must answer two questions:
1. Will the tool pass the pipeline?
2. Will it accurately assess defects?

The most advanced inspection technology in the world means nothing if it gets stuck 10 kilometers into a run—or delivers terrible data while running through a pipe.

That is where pull-through and push-through testing come in.

While similar, the two methods serve different roles in validating ILI tool performance.

Push-Through Testing

Push-through testing focuses on mechanical passage and operational performance.

In this setup, engineers propel the tool through a test string using hydraulic or pneumatic force. This allows them to evaluate:
• Passage through restrictions and tight tolerances
• Tool flexibility in bends and diameter changes
• Compression behavior under forward load
• Mechanical wear over long distances

Because the tool is driven dynamically through the line, push-through testing helps determine whether it can both navigate the pipeline geometry and operate reliably under realistic movement conditions.

However, these tests are resource-intensive, typically requiring pumps, large water volumes, and larger execution teams.

Pull-Through Testing

Pull-through testing focuses primarily on defect detection performance under controlled conditions.

Here, the tool is pulled through the pipeline using a winch or similar system, allowing engineers to evaluate:
• Ability to detect and size defects
• Signal quality and sensor response
• Magnetization effectiveness in thick-wall pipelines (for MFL tools)

Pull-through testing is ideal for validating inspection capability without the added complexity of setting-up a massive pump & bringing a large team to the test yard.

However, pull-through testing does not fully replicate real operating conditions or flow-driven tool behavior. It is also not possible for technologies that rely on liquid coupling, such as ultrasonic testing.

Push-Through vs. Pull-Through Wrap Up

• Push-through = navigation and operational validation
• Pull-through = controlled defect detection validation

In practice, both methods are often used together to prepare a tool prior to deployment.
